Estufa de secado al vacío WOV 200°C 10-750mmHg, WITEG
3.830,70€ – 4.539,47€
Ideal for:
- drying, baking, conditioning, curing, out-glassing solids and liquids, vacuum embedding, moisture testing, plating and aging test
Features:
- very easy and convenient for vacuuming and venting, easy to read vacuum gauge
- high quality door sealing: high temperature grade silicone molded gasket
- superior uniformity and stability
- safety window: tempered safety glass 12T & polycarbonate 5T
- RS232C interface for monitoring and controlling (WireRemote)
- stainless steel interior, powder-coated steel body and glass wool insulation
- 2x aluminium shelves included
- storage function for set values of alarm and timer
- backlight LCD display
- CE & UL/CUL certified and unique serial number for tracing
Safety mechanism:
- locking mode
- overheat and over-current protection
- sensor error detection and leakage breaker
Controller:
- Jog-Dial controller (PID) with 2-way knob (turn and push), digital LCD with backlight, and two durable setting buttons
Recommended vacuum pump for 18.6l- and 30l-oven: Rocker 810
Recommended vacuum pump for 70l-oven: Rocker 800/Rocker 811
Drying oven WOV, 2 aluminium shelves, power cable, instruction manual
»Mostrar...+»
Features
Jog-Dial controller:
- ergonomic design for easy and convenient usage
- 2-way Jog-Dial knob provides simple setting of required temperature and time
- high quality illuminated LCD
- „MAIN“ and „SUB“ button to access all menus
Temperature uniformity successfully tested by ASTM standards:All incubators and ovens are thoroughly tested, using 12 temperature sensors and the latest instruments to obtain validation, which corresponds to international standards.
Green product:All incubators and ovens achieve minimum power consumption by using heating elements consuming minimum power adjusted for the capacity and temperature of the chamber.
»Mostrar...-»
Descripción
Filters
Sort results
Reset
Apply
Referencia
| Disp | Modelo | W x D x H mm (internal) | W x D x H mm (external) | Tiempo de calentamiento | Heating power | Vacuum range | N.º de estantes | Capacidad | Precio | Su precio | Cantidad | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
DH.WOV03020 |
Unidad(es) disponible(s) bajo pedido Consulte stock y plazo de entrega |
WOV-20 230 V |
265 x 290 x 265
|
480 x 475 x 552
|
60 min. a 100°C, 90 min. a 150°C |
2 x 170 W, 2 x 130 W
|
10 - 750 mmHg, 0.63 mbar, 0.39 mbar/h
|
2 estantes de aluminio incluidos, altura entre estantes 87 mm |
18,6 L |
3.833,77€
(s/IVA)
|
|||
DH.WOV03030 |
Unidad(es) disponible(s) bajo pedido Consulte stock y plazo de entrega |
WOV-30 230 V |
300 x 330 x 300
|
515 x 515 x 587
|
70 min. a 100°C, 100 min. a 150°C |
2 x 170 W, 2 x 130 W
|
10 - 750 mmHg, 0.63 mbar, 0.39 mbar/h
|
2 estantes de aluminio incluidos, altura entre estantes 98 mm |
30 L |
3.830,70€
(s/IVA)
|
|||
DH.WOV03070 |
Unidad(es) disponible(s) bajo pedido Consulte stock y plazo de entrega |
WOV-70 230 V |
400 x 435 x 400
|
618 x 620 x 687
|
80 min. a 100°C, 100 min. a 150°C |
2 x 350 W, 2 x 450 W
|
10 - 750 mmHg, 0.63 mbar, 0.39 mbar/h
|
2 estantes de aluminio incluidos, altura entre estantes 133 mm |
70 L |
4.539,47€
(s/IVA)
|
Descargas
| Documento
|
Título
|
|
| Catálogo |  |
WOV EN.pdf |
| Manual | |
WOV deutsch_englisch V2.1.10102016 DE EN.pdf |
