Estufa de secado al vacío WOV 200°C 10-750mmHg, WITEG

3.830,70€ – 4.539,47€

Ideal for:

  • drying, baking, conditioning, curing, out-glassing solids and liquids, vacuum embedding, moisture testing, plating and aging test

Features:

  • very easy and convenient for vacuuming and venting, easy to read vacuum gauge
  • high quality door sealing: high temperature grade silicone molded gasket
  • superior uniformity and stability
  • safety window: tempered safety glass 12T & polycarbonate 5T
  • RS232C interface for monitoring and controlling (WireRemote)
  • stainless steel interior, powder-coated steel body and glass wool insulation
  • 2x aluminium shelves included
  • storage function for set values of alarm and timer
  • backlight LCD display
  • CE & UL/CUL certified and unique serial number for tracing

Safety mechanism:

  • locking mode
  • overheat and over-current protection
  • sensor error detection and leakage breaker

Controller:

  • Jog-Dial controller (PID) with 2-way knob (turn and push), digital LCD with backlight, and two durable setting buttons

Recommended vacuum pump for 18.6l- and 30l-oven: Rocker 810
Recommended vacuum pump for 70l-oven: Rocker 800/Rocker 811

Drying oven WOV, 2 aluminium shelves, power cable, instruction manual

»Mostrar...+»

Features

Jog-Dial controller:

  • ergonomic design for easy and convenient usage
  • 2-way Jog-Dial knob provides simple setting of required temperature and time
  • high quality illuminated LCD
  • „MAIN“ and „SUB“ button to access all menus

Temperature uniformity successfully tested by ASTM standards:All incubators and ovens are thoroughly tested, using 12 temperature sensors and the latest instruments to obtain validation, which corresponds to international standards.

Green product:All incubators and ovens achieve minimum power consumption by using heating elements consuming minimum power adjusted for the capacity and temperature of the chamber.

»Mostrar...-»

SKU: DH.WOV Categoría:

Descripción

Add selected ()
Add selected ()
Add selected items to cart
Select all
Clear all
Filters Sort results
Reset Apply
Referencia
Modelo
W x D x H mm (internal)
W x D x H mm (external)
Tiempo de calentamiento
Heating power
Vacuum range
N.º de estantes
Capacidad
Disp
Precio
Su precio
Cantidad
DH.WOV03020

WOV-20 230 V

265 x 290 x 265
480 x 475 x 552
60 min. a 100°C, 90 min. a 150°C
2 x 170 W, 2 x 130 W
10 - 750 mmHg, 0.63 mbar, 0.39 mbar/h
2 estantes de aluminio incluidos, altura entre estantes 87 mm
18,6 L
Bajo pedido. Consultar plazo entrega.
3.833,77€
Sign In
Max:
Min: 1
Step: 1
DH.WOV03030

WOV-30 230 V

300 x 330 x 300
515 x 515 x 587
70 min. a 100°C, 100 min. a 150°C
2 x 170 W, 2 x 130 W
10 - 750 mmHg, 0.63 mbar, 0.39 mbar/h
2 estantes de aluminio incluidos, altura entre estantes 98 mm
30 L
Bajo pedido. Consultar plazo entrega.
3.830,70€
Sign In
Max:
Min: 1
Step: 1
DH.WOV03070

WOV-70 230 V

400 x 435 x 400
618 x 620 x 687
80 min. a 100°C, 100 min. a 150°C
2 x 350 W, 2 x 450 W
10 - 750 mmHg, 0.63 mbar, 0.39 mbar/h
2 estantes de aluminio incluidos, altura entre estantes 133 mm
70 L
Bajo pedido. Consultar plazo entrega.
4.539,47€
Sign In
Max:
Min: 1
Step: 1

Descargas

Documento

 Título
Catálogo WOV EN.pdf
Manual WOV deutsch_englisch V2.1.10102016 DE EN.pdf
